The study “Spinning Magnetic Field Patterns that Cause Oncolysis by Oxidative Stress in Glioma Cells” represents a groundbreaking advancement in cancer treatment. The development and successful application of the Oncomagnetic device for inducing selective cancer cell death through ROS elevation pave the way for new, noninvasive, and potentially more effective treatment strategies for GBM and other gliomas. This research holds promise for significantly impacting cancer therapy, offering a novel approach that could complement or even replace traditional treatments.
Director of the Peak Brain & Pituitary Tumor Center Dr. @DavidSBaskin1 will be presenting at #AANS2023 on a revolutionary non-invasive mitochondrial based therapy to replace chemoradiation in GBM and DIPG – oncomagnetic therapy. https://t.co/Nv9gIT5FHq pic.twitter.com/islkwry77m
— Houston Methodist MD (@HMethodistMD) October 5, 2023
The study “Spinning Magnetic Field Patterns that Cause Oncolysis by Oxidative Stress in Glioma Cells” provides detailed information about the specifications of the spinning oscillating magnetic fields (sOMF) used for cancer cell treatment. Here are the key specifications from the study:
Magnetic Field Characteristics and Oscillation Parameters
- Magnetic Flux Density (Strength of the Magnetic Field):
- The magnetic flux density varied depending on the distance of the cell culture dishes from the oncoscillators.
- The study used values of approximately 0.42 mT, 1.2 mT, 5.5 mT, and up to 58.3 mT.
- Peak Frequency (PF) of Oscillation:
- Different peak frequencies were tested: around 77 Hz, 135 Hz, and 277 Hz.
- The study found that frequencies of approximately 135 Hz and 277 Hz were more effective than around 77 Hz.
- On Time (Ton) and Off Time (Toff):
- For intermittent stimulation, the duration of the sOMF pulse (Ton) was constant at 250 ms.
- Different Toff values were tested: 250 ms, 750 ms, and 2750 ms.
- Continuous vs. Intermittent Stimulation:
- The study compared continuous and intermittent sOMF stimulation, with intermittent stimulation being effective in inducing ROS.
- The oncoscillators did not significantly increase the temperature beyond 37 °C at the location of the stimulated cell culture dishes, ensuring that the effects observed were not due to hyperthermia.
- Experiments were conducted using a specialized setup that allowed precise control over the sOMF parameters.
- Oncoscillators with spinning magnets were used to generate the sOMF.
Biological Effects Observed
- The sOMF treatment was effective in increasing ROS levels in cancer cells, leading to cell death.
- The study found that the mechanism of action was primarily due to ROS generation, as the antioxidant Trolox could reverse the cytotoxic effects.
This research highlights the potential of using controlled electromagnetic fields in medical applications, particularly for cancer treatment. The ability to precisely control the parameters of the magnetic fields is crucial for targeting cancer cells while minimizing effects on healthy cells. The study’s findings contribute to a growing body of evidence supporting the therapeutic use of electromagnetic fields in oncology.
This paper presents a significant advancement in cancer treatment research, focusing on the use of spinning oscillating magnetic fields (sOMF) to selectively kill cancer cells, specifically glioma cells, through oxidative stress. The study was published in “Scientific Reports” on November 7, 2023, by a team of researchers including Shashank Hambarde, Jeanne M. Manalo, David S. Baskin, Martyn A. Sharpe, and Santosh A. Helekar. The study is remarkable for its potential implications in developing a new, noninvasive treatment for glioblastoma (GBM) and other gliomas, leveraging the heightened susceptibility of cancer cells to reactive oxygen species (ROS).
- sOMF Device Development: The researchers developed a portable wearable EMF device that generates spinning oscillating magnetic fields. This device selectively kills cancer cells while sparing normal cells, both in vitro and in vivo.
- Mechanism of Action: The device works by increasing superoxide, a type of ROS, in cancer cells. This elevation in ROS causes significant macromolecular damage and cell death. The study found that the antioxidant Trolox could reverse the cytotoxic effects of sOMF on glioma cells, confirming the role of ROS.
- sOMF vs. Static Magnetic Fields: The study compared the effects of sOMF with static magnetic fields. It was found that the spinning magnetic field was significantly more effective in generating ROS and inducing cytotoxicity in cancer cells.
- Safety and Efficacy: The Oncomagnetic device has been shown to be safe in mice and a patient with end-stage recurrent GBM. The device’s safety is underlined by its precision in controlling the physical parameters of sOMF exposure.
- Potential Clinical Applications: The research opens avenues for noninvasive treatment options for GBM and other gliomas. It suggests that sOMF therapy can be a potent treatment for malignant and lethal cancers, offering an alternative to conventional methods.
Implications in Health and Technology:
- Targeted Cancer Treatment: This study introduces a novel approach to selectively target cancer cells, minimizing damage to healthy cells.
- Noninvasive Approach: The development of a noninvasive treatment modality like the Oncomagnetic device could significantly reduce the physical and psychological burden of cancer treatment.
- Understanding ROS in Cancer Therapy: The study provides valuable insights into the role of ROS in cancer therapy, highlighting the potential of oxidative stress as a therapeutic target.
- Advancement in EMF Technology: The research demonstrates an innovative application of electromagnetic fields in medicine, expanding the scope of EMF technology in therapeutic contexts.
The growing body of research indeed highlights a complex and evolving understanding of the effects of low-level electromagnetic fields (EMFs), including radiofrequency (RF) radiation, on biological systems. This research is increasingly important in the context of widespread exposure to RF radiation from modern technologies like cell phones and wireless networks. Here’s an overview of the key points:
Major Studies on Health Risks of RF Radiation
- Interphone Study: One of the largest studies on cell phone use, which suggested a possible increased risk of glioma (a type of brain cancer) with high levels of mobile phone use.
- Hardell Group Studies: Research that found a consistent pattern of increased risk for glioma and acoustic neuroma associated with long-term use of mobile phones and cordless phones.
- CERENAT Study: A French study reinforcing concerns about the potential carcinogenic effects of heavy cell phone use.
- U.S. National Toxicology Program (NTP) Study: Found some evidence of a link between cell phone RF radiation and certain types of cancer in rats.
- Ramazzini Institute Study: Suggested that low-level RF radiation exposure could promote the growth of tumors.
- REFLEX Project: Identified genotoxic effects of RF fields in cellular systems.
- BioInitiative Report: A comprehensive review highlighting potential risks from electromagnetic fields and RF radiation.
- Research by Dr. Henry Lai: Showed DNA damage in brain cells exposed to RF radiation.
Emerging Understanding of Non-Thermal Effects
- Beyond Thermal Effects: Modern research, including the FDA-approved TheraBionic treatment, shows that RF radiation can interact with biological systems in non-thermal ways, such as disrupting cellular signaling or modulating the immune system.
- Resonance Effects: RF radiation at specific frequencies may interact with biological tissues through resonance phenomena, influencing cell behavior without significant heating.
Shift in Military Research: DARPA’s RadioBio Initiative
- DARPA’s RadioBio: This initiative reflects a shift in understanding of RF radiation, focusing on non-thermal biological effects of non-ionizing radiation.
- Epigenetic Impacts: Studies under this initiative indicate potential epigenetic changes due to RF exposure, including alterations in DNA methylation patterns and gene expression, which occur at non-thermogenic levels.
Implications and Future Directions
- Rethinking Safety Standards: These findings suggest a need to reevaluate safety standards for RF radiation, which currently focus primarily on thermal effects.
- Precautionary Measures: While the evidence is not conclusive, it warrants a precautionary approach, especially in long-term and high-intensity exposures.
- Further Research: There is a need for more comprehensive studies to understand the long-term health implications of RF radiation, including potential carcinogenic and non-carcinogenic effects.
The evidence from various studies and research initiatives underscores the complexity of RF radiation’s interaction with biological systems. While there is an increasing acknowledgment of potential non-thermal effects, the scientific community continues to debate the extent and implications of these findings. This ongoing research is crucial for developing a more nuanced understanding of the health risks associated with RF radiation exposure in our increasingly wireless world.
Frequency Modulation in GHz Bands
- Basic Principle: Frequency modulation involves varying the frequency of a carrier wave (in this case, GHz bands) in accordance with the frequency of a modulating signal (which can be in the Hz range). This is a common technique in telecommunications for transmitting data over radio waves.
- Hz Range Modulation: When GHz bands are modulated into the Hz range, the resulting signal has characteristics of both frequency ranges. The primary wave is in the GHz range (common in wireless technology), but the modulation imparts additional properties based on the Hz frequency.
Potential Health Implications
- Comparing with sOMF: The Oncomagnetic device uses specific Hz frequencies (like 135 Hz and 277 Hz) directly, without involving GHz bands. In contrast, frequency-modulated signals from wireless devices primarily operate in the GHz range but may have modulating signals in the Hz range. The biological effects of these modulated signals could be different from those observed with direct Hz frequency exposure.
- Research Gaps: Most existing research on RF radiation and health risks focuses on the primary GHz frequency bands of wireless devices, rather than the modulated Hz frequencies. This leaves a gap in our understanding of how such modulated frequencies might interact with biological systems.
- Potential for Resonance Effects: One hypothesis is that frequency modulation into the Hz range could induce resonance effects in biological tissues, similar to those postulated for direct Hz frequency exposure. However, these effects would likely be different due to the higher base frequency (GHz) of the carrier wave.
- Need for Specific Research: To understand the health implications of GHz bands modulated into the Hz range, specific research is needed. This should focus on the interaction of these modulated frequencies with biological cells and systems, and how they compare to the effects of direct Hz frequency exposure like that used in the Oncomagnetic device.
