Google Pixel 6A Radiation Levels


Google Pixel 6a SAR Level Summary: View Thermal Visualization
The cellular transmission SAR values for the Google Pixel 6a (FCC ID A4RGB62Z) are 1.10 W/kg (watts per kilogram) at the head and 1.16 W/kg when worn on the body. The hotspot/Airplay SAR level is 1.00 W/kg. The simultaneous transmission SAR values for (cellular plus Wi-Fi) is 1.58 W/kg at the head, 1.45 W/kg when worn on the body, and 1.59 W/kg when used as a hotspot simultaneously with other transmitters active.


Google Pixel 6A - SAR Levels

FCC SAR Levels

  • FCC Approval Date This is the date the phone SAR test was completed before the phone's release to the public as required by law.
    25 January 2022
  • FCC ID The FCC ID is the code used to register a device for FCC compliance
    A4RGB62Z
  • FCC Report Link A direct link to the FCC's website for confirming SAR levels that are listed on our website - We did the homework for you!
  • US SAR Ratings USA Legal Limit is 1.6 W/kg
    USA Legal Limit is 1.6 W/kg - FCC SAR testing is measured in watts per kilogram (or W/kg) averaged over ONE gram of simulated biological tissue.
  • Head SAR Level SAR test when held against your head when only using cellular service. Wifi and other transmitter are NOT active
    1.10 W/kg
  • Body SAR Level SAR test when held against your body only using cellular service. Wifi and other transmitter are NOT active
    1.16 W/kg
  • Product Specific Use SAR test when held against your body only using the phone as a hotspot. Cellular and other transmitter are NOT active
    1.00 W/kg
  • Simultaneous Transmission The highest possible SAR recorded with ALL transmitters active, Cellular, WiFi, and Hotspot
    1.59 W/kg
  • Simultaneous Head The highest possible SAR test when held against your HEAD with cellular and WiFi transmitters active,
    1.578 W/kg
  • Simultaneous Body The highest possible SAR test when held against your BODY with cellular and WiFi transmitters active,
    1.453 W/kg
  • Hotspot SAR The highest possible SAR test when held against your BODY using the phone as a hotspot with cellular and WiFi transmitters active,
    1.589 W/kg

EU SAR Level

  • EU SAR Ratings
    European Legal Limit is 2.0 W/kg - EU SAR testing is measured in watts per kilogram (or W/kg) averaged over TEN grams of simulated biological tissue.
  • Head SAR Level
    0.99 W/kg
  • Body SAR Level
    1.31 W/kg

Updated on December 30th, 2022 at 11:45 am

The guidelines use a unit of measurement known as Specific Absorption Rate (“SAR”) which is a unit of body-absorbed radio frequency quantity when the phone is in use. The SAR limit in India for mobile devices is 1.6 W/kg over a mass of 1 gram of human tissue.

Pixel 6a complies with these guidelines when used against head with no separation and body with 10 mm separation. Ensure that device accessories, such as device case and device holster, are not composed of metal components. Keep the device away from your body to meet the distance requirement.

For Pixel 6a , the highest Specific Absorption Rate (SAR) values reported are

  • Head: 1.10 W/kg,
  • Body: 1.16 W/kg.

You can also see SAR values on the website of the DoT/ Telecommunication Engineering Centre.

While most of the laboratory studies have been unable to find a direct link between exposure to radio frequency radiation and health, the DoT has prescribed the following precautionary measures while using the mobile handset:

  • Use a wireless hands-free system (headphone, headset) with a lower power Bluetooth emitter.
  • Make sure the cell phone has a low SAR. Keep your calls short or send a text message (SMS) instead. This advice applies especially to children, adolescents, and pregnant women.
  • Use cell phone when the signal quality is good. People having active medical implants should preferably keep the cell phone at least 15 cm away from the implant.
Network Technology GSM / HSPA / LTE / 5G
2G bands GSM 850 / 900 / 1800 / 1900
3G bands HSDPA 800 / 850 / 900 / 1700(AWS) / 1900 / 2100
4G bands 1, 2, 3, 4, 5, 7, 8, 12, 13, 14, 17, 18, 19, 20, 25, 26, 28, 29, 30, 38, 39, 40, 41, 42, 48, 66, 71 – GX7AS, GB62Z (USA/Canada)
1, 2, 3, 4, 5, 7, 8, 12, 13, 14, 17, 18, 19, 20, 25, 26, 28, 29, 30, 32, 38, 39, 40, 41, 42, 48, 66, 71 – G1AZG (International)
5G bands 1, 2, 3, 5, 7, 8, 12, 20, 25, 28, 30, 38, 40, 41, 48, 66, 71, 77, 78 SA/NSA/Sub6 – GX7AS (USA/Canada)
1, 2, 3, 5, 7, 8, 12, 20, 25, 28, 30, 40, 48, 66, 71, 77, 78, 260, 261 SA/NSA/Sub6/mmWave – GB62Z (USA)
1, 2, 3, 5, 7, 8, 12, 20, 25, 28, 30, 40, 48, 66, 71, 77, 78 SA/NSA/Sub6 – G1AZG (International)
Speed HSPA 42.2/5.76 Mbps, LTE-A (CA), 5G
Launch Announced 2022, May 11
Status Available. Released 2022, July 21
Body Dimensions 152.2 x 71.8 x 8.9 mm (5.99 x 2.83 x 0.35 in)
Weight 178 g (6.28 oz)
Build Glass front (Gorilla Glass 3), aluminum frame, plastic back
SIM Nano-SIM and/or eSIM
IP67 dust/water resistant (up to 1m for 30 mins)
Display Type OLED, HDR
Size 6.1 inches, 90.7 cm2 (~83.0% screen-to-body ratio)
Resolution 1080 x 2400 pixels, 20:9 ratio (~429 ppi density)
Protection Corning Gorilla Glass 3
Always-on display
Platform OS Android 12
Chipset Google Tensor (5 nm)
CPU Octa-core (2×2.80 GHz Cortex-X1 & 2×2.25 GHz Cortex-A76 & 4×1.80 GHz Cortex-A55)
GPU Mali-G78 MP20
Memory Card slot No
Internal 128GB 6GB RAM
UFS 3.1
Main Camera Dual 12.2 MP, f/1.7, 27mm, (wide), 1/2.55″, 1.4m, dual pixel PDAF, OIS
12 MP, f/2.2, 17mm, 114 (ultrawide), 1.25m
Features Dual-LED flash, Pixel Shift, Auto-HDR, panorama
Video 4K@30/60fps, 1080p@30/60/120/240fps; gyro-EIS, OIS
Selfie camera Single 8 MP, f/2.0, 24mm (wide), 1.12m
Features Auto-HDR, panorama
Video 1080p@30fps
Sound Loudspeaker Yes, with stereo speakers
3.5mm jack No
Comms WLAN Wi-Fi 802.11 a/b/g/n/ac/6e, dual-band, Wi-Fi Direct, hotspot
Bluetooth 5.2, A2DP, LE
GPS Yes, with A-GPS, GLONASS, GALILEO, QZSS
NFC Yes
Radio No
USB USB Type-C 3.1
Features Sensors Fingerprint (under display, optical), accelerometer, gyro, proximity, compass, barometer
Battery Type Li-Po 4410 mAh, non-removable
Charging Fast charging 18W
USB Power Delivery 3.0
Misc Colors Chalk, Charcoal, Sage
Models GX7AS, GB62Z, G1AZG
Price $ 419.99 / £ 399.00 / € 459.00

Google Pixel 6A - Specs sar

General

  • Device Type
    Cell Phone
  • Model
    google
  • Announced
    23 December 2021
  • Released
    23 December 2021
  • Status
    Available

Design

  • Type Design Type called form factor refers to a mobile phone's size, shape, and style as well as the layout and position of major components of phone. There are three major form factors seen in mobile phones => bar phones, folding phones and sliding phones.
    Bar
  • Dimensions
    152.2 x 71.8 x 8.9 mm (5.99 x 2.83 x 0.35 in)
  • Weight
    178 g (6.28 oz)BuildGlass front (Gorilla Glass 3), aluminum frame, plastic back
  • Protection
    Corning Gorilla Glass 3 Always-on display
  • Colors
    Chalk, Charcoal, SageModelsGX7AS, GB62Z, G1AZG

Network

  • 2G Network
    bandsGSM 850 / 900 / 1800 / 1900
  • 3G Network
    bandsHSDPA 800 / 850 / 900 / 1700(AWS) / 1900 / 2100
  • 4G Network
    bands1, 2, 3, 4, 5, 7, 8, 12, 13, 14, 17, 18, 19, 20, 25, 26, 28, 29, 30, 38, 39, 40, 41, 42, 48, 66, 71 - GX7AS, GB62Z (USA/Canada) 1, 2, 3, 4, 5, 7, 8, 12, 13, 14, 17, 18, 19, 20, 25, 26, 28, 29, 30, 32, 38, 39, 40, 41, 42, 48, 66, 71 - G1AZG (International)5G bands1, 2, 3, 5, 7, 8, 12, 20, 25, 28, 30, 38, 40, 41, 48, 66, 71, 77, 78 SA/NSA/Sub6 - GX7AS (USA/Canada) 1, 2, 3, 5, 7, 8, 12, 20, 25, 28, 30, 40, 48, 66, 71, 77, 78, 260, 261 SA/NSA/Sub6/mmWave - GB62Z (USA) 1, 2, 3, 5, 7, 8, 12, 20, 25, 28, 30, 40, 48, 66, 71, 77, 78 SA/NSA/Sub6 - G1AZG (International)
  • SIM SIM (Subscriber Identity Module) is a small card that contains mobile network subscriber's account information. This allows the phone using the card to attach to a mobile network. The SIM card is most commonly associated with GSM and UMTS mobile networks. Moving a SIM card from one phone to another allows a subscriber to switch mobile phones without having to contact their mobile network carrier. SIM cards can also be used by a phone to store limited amounts of data, such as phone numbers and text messages.
    Standard SIM

Display

  • Type Display Technology => A number of display technologies and types used in mobile phones => TFT (Thin Film Transistor), IPS (In-Place Switching), OLED (Organic Light Emitting Diode), AMOLED (Active-Matrix Organic Light-Emitting Diode), Super AMOLED (an even advanced version of AMOLED), Resistive Touchscreen (Resistive touchscreens contain two layer of conductive material with a very small gap between them which acts as a resistance), Capacitive Touchsceen (Capacitive touchscreen technology consists of a layer of glass coated with a transparent conductor)
    OLED, HDR
  • Size
    6.1 inches, 90.7 cm2 (~83.0% screen-to-body ratio)Resolution1080 x 2400 pixels, 20:9 ratio (~429 ppi density)ProtectionCorning Gorilla Glass 3 Always-on display
  • Resolution
    OLED, HDR
  • Colors Display Colors is refers to the number of different shades of colors that the screen is capable of displaying => 64K colors, 256K colors and 16 million colors, Obviously 16M is highest available range of colors and better than others.
    Chalk, Charcoal, SageModelsGX7AS, GB62Z, G1AZG
  • Pixel Density Pixel Density (PPI) is refers to the concentration of pixels on a particular display, measured in pixels per inch (ppi). Pixel density is calculated by dividing the diagonal pixel resolution of a display by its diagonal size, higher pixel density better display quality.
    6.1 inches, 90.7 cm2 (~83.0% screen-to-body ratio)Resolution1080 x 2400 pixels, 20:9 ratio (~429 ppi density)ProtectionCorning Gorilla Glass 3 Always-on display
  • Touch Screen
    OLED, HDR
  • Protection Display Protection => Gorilla Glass is a special alkali-aluminosilicate glass shield with exceptional damage resistance that helps protect mobile displays from scratches, drops, and bumps of everyday use, It is always better to go for a smartphone with Gorilla Glass for that added protection and peace of mind.
    Corning Gorilla Glass 3 Always-on display
  • Features
    SensorsFingerprint (under display, optical), accelerometer, gyro, proximity, compass, barometer
  • Secondary Display
    Single8 MP, f/2.0, 24mm (wide), 1.12mFeaturesAuto-HDR, panoramaVideo1080p@30fps

Media

  • Audio Playback
    N/A
  • Video Playback
    4K@30/60fps, 1080p@30/60/120/240fps; gyro-EIS, OIS
  • Video Out
    4K@30/60fps, 1080p@30/60/120/240fps; gyro-EIS, OIS
  • FM Radio
    No
  • Ring Tones
    yes
  • Loudspeaker
    Yes, with stereo speakers
  • Handsfree
    No

Camera

  • Primary Camera is able to capture photographs and usually videos, The most important characteristics of a camera are the resolution (measured in megapixels), lens focus type (fixed or automatic), higher megapixel cameras are known to capture higher quality photos, but not always a good measurement of the photos quality.
    Dual12.2 MP, f/1.7, 27mm, (wide), 1/2.55
  • Image
    Single8 MP, f/2.0, 24mm (wide), 1.12mFeaturesAuto-HDR, panoramaVideo1080p@30fps
  • Video
    4K@30/60fps, 1080p@30/60/120/240fps; gyro-EIS, OIS
  • Features
    Dual-LED flash, Pixel Shift, Auto-HDR, panorama
  • Flash Flash Light => There is commonly two types of flash lights are used in camera mobile phones, LED Flash (LED flash offers lower power consumption with drive circuitry that takes up very little room, LEDs can be strobed faster than any other light source), Xenon Flash (xenon flash produces an extremely intense full-spectrum white light for a very short duration)
    Yes
  • Secondary
    Single8 MP, f/2.0, 24mm (wide), 1.12mFeaturesAuto-HDR, panoramaVideo1080p@30fps

Software

  • Operating System OS => Every computer system run on a base software called Operating System (OS). Operating System controls all basic operations of the computer (such as smartphone, PDAs, tablet computers and other handheld devices). The Operating System allows the user to install and run third party applications (apps), apps are used to add new functionality to the device.
    OSAndroid 12
  • User Interface UI or user interface of a device is the look and feel of the on-screen menu system. How it works, its color scheme, how it responds to button presses, all of these things are part of the user interface.
    OLED, HDR
  • Java Support Java for Mobile Devices is a set of technologies that let developers deliver applications and services to all types of mobile handsets, ranging from price efficient feature-phones to the latest smartphones. Java is currently running on over 3 billion phones worldwide, and growing. It offers unrivaled potential for the distribution and monetization of mobile applications.
    N/A

Hardware

  • Chipset Chipset is a group of integrated circuits designed to perform one or a more dedicated functions, often with real time computing constraints, Popular smartphones are equipped with more advanced embedded chipsets that can do many different tasks depending on their programming.
    Google Tensor (5 nm)
  • CPU CPU (Central Processing Unit) mostly known as processors, CPU processes instructions in order to carry out certain functions that make your device operate properly. Processors are often described as the brain of computers, smartphones and tablets, Smartphones and tablets rely on processors to carry out their every task, Processors are an incredibly important factor in selecting any type of computing device, including your smartphone.
    Octa-core (2x2.80 GHz Cortex-X1 & 2x2.25 GHz Cortex-A76 & 4x1.80 GHz Cortex-A55)
  • GPU GPU (Graphics Processing Unit) is a single-chip processor designed to rapidly manipulate and alter memory to accelerate the creation of images in a frame buffer intended for output to a display, This includes things such as lighting effects, object transformations, and 3D motion.
    Mali-G78 MP20
  • RAM (Memory) RAM (Random Access Memory) is a type of computer memory that can be accessed randomly, any byte of memory can be accessed without touching the preceding bytes that allows information to be stored and accessed quickly from random locations. RAM is the most common type of memory found in computer systems, smartphones, tablets and other electronic devices.
    128GB 6GB RAM UFS 3.1
  • Internal Storage Internal Storage is a data storage space (flash memory) mostly used in smartphones, tablets and other electronic devices where operating system, apps, music, photos, videos, files and other user data Is stored.
    128GB 6GB RAM UFS 3.1
  • Card Slot Memory Card Slot is a special slot for inserting a memory card. Memory cards allow you to expand the phone's built-in memory, A memory card (sometimes called a flash memory card or a storage card) is a small storage medium used to store data such as text, pictures, audio, and video, for use on small, portable or remote computing devices such as mobile phones, mp3 players, digital cameras.
    Card slotNo
  • Sensors Sensors are electronic components that detects and responds to some type of input from the physical environment. The specific input could be light, heat, motion, moisture, pressure and location, The output is generally a signal that is converted to use in computing systems, a location sensor, such as a GPS receiver is able to detect current location of your electronic device.
    Fingerprint (under display, optical), accelerometer, gyro, proximity, compass, barometer BatteryTypeLi-Po 4410 mAh, non-removableChargingFast charging 18WUSB Power Delivery 3.0MiscColorsChalk, Charcoal, SageModelsGX7AS, GB62Z, G1AZGPrice$ 419.99 / £ 399.00 / € 459.00

Connectivity

  • Bluetooth Bluetooth is a wireless communications technology for exchanging data between mobile phones, headsets, computers and other network devices over short distances without wires, Bluetooth technology was primarily designed to support simple wireless networking of personal consumer devices.
    5.2, A2DP, LE
  • Wi-fi Wi-Fi is a popular wireless networking technology using radio waves to provide high-speed network connections that allows devices to communicate without cords or cables, Wi-Fi is increasingly becoming the preferred mode of internet connectivity all over the world.
    Wi-Fi 802.11 a/b/g/n/ac/6e, dual-band, Wi-Fi Direct, hotspot
  • GPS GPS The Global Positioning System is a satellite-based radio navigation system, GPS permits users to determine their position, velocity and the time 24 hours a day, in all weather, anywhere in the world, In order to locate your position, your device or GPS receiver must have a clear view of the sky.
    Yes, with A-GPS, GLONASS, GALILEO, QZSS NFCYes
  • Wireless Charging Wireless Charging (Inductive Charging) uses an electromagnetic field to transfer energy between two objects. This is usually done with a charging station. Energy is sent through an inductive coupling to an electrical device, which can then use that energy to charge batteries or run the device.
    no

Data

  • Speed
    HSPA 42.2/5.76 Mbps, LTE-A (CA), 5GLaunchAnnounced2022, May 11StatusAvailable. Released 2022, July 21BodyDimensions152.2 x 71.8 x 8.9 mm (5.99 x 2.83 x 0.35 in)Weight178 g (6.28 oz)BuildGlass front (Gorilla Glass 3), aluminum frame, plastic backSIMNano-SIM and/or eSIM IP67 dust/water resistant (up to 1m for 30 mins)DisplayTypeOLED, HDRSize6.1 inches, 90.7 cm2 (~83.0% screen-to-body ratio)Resolution1080 x 2400 pixels, 20:9 ratio (~429 ppi density)ProtectionCorning Gorilla Glass 3 Always-on displayPlatformOSAndroid 12ChipsetGoogle Tensor (5 nm)CPUOcta-core (2x2.80 GHz Cortex-X1 & 2x2.25 GHz Cortex-A76 & 4x1.80 GHz Cortex-A55)GPUMali-G78 MP20MemoryCard slotNoInternal128GB 6GB RAM UFS 3.1Main CameraDual12.2 MP, f/1.7, 27mm, (wide), 1/2.55
  • Web Browser Web Browser => a web browser is a software application used to locate, retrieve and display content on the World Wide Web, including Web pages, images, video and other files, The primary function of a web browser is to render HTML, the code used to design or markup webpages.
    N/A

Messaging

  • SMS SMS (Short Messaging Service) is a text messaging service component of phone, Web, or mobile communication systems. It uses standardized communications protocols to allow mobile phone devices to exchange short text messages over the networks.
    No
  • Email Email (Electronic Mail) is a system for receiving, sending, and storing electronic messages, Similar to a letter, email is text messages that may contain files, images, or other attachments sent via the internet to a recipient by using applications and software prograps. An email address is required to receive email, and that address is unique to the user.
    yes
  • IM IM (Instant Messaging) is an exchange of text messages through a software application, it enable you to create a kind of private chat room with another individual in order to communicate in real time over the Internet.
    yes

Battery

  • Type Battery Type => Cell phones run on various kinds of batteries depending on the manufacturer, phone size or shape and features. There are basically four types of cell phone batteries => Lithium Polymer, Lithium Ion, Nickel Metal Hydride and Nickel Cadmium.
    Li-Ion (Lithium Ion)

FCC SAR Levels

  • FCC Approval Date This is the date the phone SAR test was completed before the phone's release to the public as required by law.
    25 January 2022
  • FCC ID The FCC ID is the code used to register a device for FCC compliance
    A4RGB62Z
  • FCC Report Link A direct link to the FCC's website for confirming SAR levels that are listed on our website - We did the homework for you!
  • US SAR Ratings USA Legal Limit is 1.6 W/kg
    USA Legal Limit is 1.6 W/kg - FCC SAR testing is measured in watts per kilogram (or W/kg) averaged over ONE gram of simulated biological tissue.
  • Head SAR Level SAR test when held against your head when only using cellular service. Wifi and other transmitter are NOT active
    1.10 W/kg
  • Body SAR Level SAR test when held against your body only using cellular service. Wifi and other transmitter are NOT active
    1.16 W/kg
  • Product Specific Use SAR test when held against your body only using the phone as a hotspot. Cellular and other transmitter are NOT active
    1.00 W/kg
  • Simultaneous Transmission The highest possible SAR recorded with ALL transmitters active, Cellular, WiFi, and Hotspot
    1.59 W/kg
  • Simultaneous Head The highest possible SAR test when held against your HEAD with cellular and WiFi transmitters active,
    1.578 W/kg
  • Simultaneous Body The highest possible SAR test when held against your BODY with cellular and WiFi transmitters active,
    1.453 W/kg
  • Hotspot SAR The highest possible SAR test when held against your BODY using the phone as a hotspot with cellular and WiFi transmitters active,
    1.589 W/kg

SAR AT&T Model

SAR Verizon Model

SAR Sprint Model

SAR T-Mobile Model

SAR Vodafone Model

SAR U.S. Cellular

EU SAR Level

  • EU SAR Ratings
    European Legal Limit is 2.0 W/kg - EU SAR testing is measured in watts per kilogram (or W/kg) averaged over TEN grams of simulated biological tissue.
  • Head SAR Level
    0.99 W/kg
  • Body SAR Level
    1.31 W/kg
